Single Solenoid Valve

Get a Price/Quote

MOQ : 1 Piece

Single Solenoid Valve Specification

Voltage
DC12V, DC24V, AC110V, AC220V

Capacity
Standard Cylinder Actuation up to 100mm bore

Noise Level
<75dB

Sealing
NBR Seals; Optional Viton

Flow Rate
430-1300 L/min

Application
Pneumatic Automation, Cylinder Actuation, Industrial Controls

Mounting Type
Base-mounting or Inline Mounting

Pressure Ratings
0.15~0.8MPa (21~114 psi)

IP Rating
IP65 (with Coil Connector)

Valve Type
5/2 Way Solenoid Valve

Diameter
8mm to 20mm (based on port size)

Connection
G (BSP) or NPT Threaded Ports

Standard
ISO 5599/1

Material
Other

Temperature
-10C to +60C

Media
Filtered Air, Lubricated or Non-lubricated

Structure
5/2 Way, Single Solenoid

Power
2.5W - 4.5W

Port Size
1/8 (8A), 1/4 (15A), 3/8 (20A)

Model
5-2 Single Solenoid Directional Control Valve

Lubrication
Not required but permissible

Manual Override
Push Button (Non-locking Type)

Electrical Entry
DIN Connector or Lead Wire

Response Time
<50 ms

Coil Duty Cycle
100% ED

Weight
Approx. 320g - 650g (varies by size)

Ambient Humidity
95% RH

Exhaust Type
Internal or External

Body Finish
Clear Anodized/Black Painted

Coil Insulation Class
Class F (155C)

O-Ring Material
Nitrile (NBR) or FKM (Viton) Optional

Spool Type
Sliding Spool

Single Solenoid Valve Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Single Solenoid Valve

Experience immaculate performance and stellar efficiency with our 5-2 Single Solenoid Directional Control Valve, crafted from top-grade aluminium alloy and featuring a glorious hard anodized sliding spool. Specially designed for reliability, the valve offers personalisation through threaded G (BSP) or NPT ports and a choice of NBR or Viton O-ring seals. Its rapid <50 ms response, non-locking manual override, and IP65 protection ensure robust functionality. Perfect for pneumatic automation and industrial applications, this valve is your trusted solution for seamless cylinder actuation.

Applications and Advantages of the 5-2 Single Solenoid Directional Control Valve

This valve excels in numerous site installations, ranging from pneumatic automation systems to industrial cylinder actuation and process control. Its adaptability makes it ideal for manufacturing plants, assembly lines, and automated machinery. Key benefits include fast response time, minimal maintenance due to optional lubrication, and a robust build suitable for harsh environments. The special push-button manual override offers operational flexibility, while the top-tier seals ensure longevity and leak prevention.

Domestic Market Reach and Distribution for the 5-2 Single Solenoid Directional Control Valve

The 5-2 Single Solenoid Directional Control Valve is widely available through dealers and suppliers across India's key industrial hubs. We ensure rapid dispatching and secure drop-off through reliable logistics partners. Quotation requests are promptly handled, and our large supply ability guarantees steady availability for bulk orders. Our standard FOB port for exports is conveniently situated for international shipments, allowing clients seamless procurement for both domestic and global requirements.

FAQ's of 5-2 Single Solenoid Directional Control Valve:

Q: How do I install the 5-2 Single Solenoid Directional Control Valve in my pneumatic system?

A: Installation involves mounting the valve either using the base or inline options, connecting threaded G (BSP) or NPT ports, and selecting the appropriate electrical entry (DIN connector or lead wire). Ensure compatibility with your system's voltage and cylinder actuation needs.

Q: What applications benefit most from this single solenoid valve?

A: This valve is optimal for pneumatic automation, industrial cylinder actuation, manufacturing lines, and process control where reliable, rapid switching and long operational life are essential.

Q: Where can I source the 5-2 Single Solenoid Directional Control Valve in India?

A: You can obtain this valve from authorized dealers and suppliers across India, with distribution in all major industrial regions and prompt delivery options.

Q: What is the process for obtaining a quotation or placing an order?

A: Simply contact our sales team or visit our dealer network. Share your requirements, port size, and preferred options, and receive a detailed quotation. Orders are promptly dispatched upon confirmation.

Q: What are the key advantages of this valve in terms of maintenance and durability?

A: The valve's hard anodized components, top-quality seals, and IP65 coil protection ensure minimal maintenance and long-term reliability-even in high-humidity or challenging industrial environments.
